The Ezy-Lift Carriage provides a cost-effective method to maintain a MASH compliant W-Beam height in Ezy-Guard Smart and Ezy-Guard 4 Barriers after a road surface overlay.
Product Information
Product Information
Product Information Product Information
- Description DescriptionDescriptionThe Ezy-Lift Carriage is an innovative height adjustment solution designed to ensure barrier compliance after road resurfacing. By allowing W-Beam guardrail to be increased in height by up to 180mm without replacing existing Ezy-Guard Posts, it provides ongoing compliance with MASH standards at a minimal cost..Features FeaturesFeatures• Crash tested and approved to MASH TL3• Accepted by the Austroads Safety Barrier Assessment Panel (ASBAP)• Designed in accordance with AS/NZS 3845.1:2015 or AS/NZS 3845.2:2017 Road Safety Barrier Systems & Devices• Lifts W-Beam by +50 mm, +100 mm, +150 mm, or +180 mm after overlays or resurfacing• Raises existing Ezy-Guard Smart, Ezy-Guard 4 and Ezy-Guard Heavy Duty (HD) barriers without replacing posts or rails• Simple retrofit with standard tools and minimal traffic disruption
- System Specifications System SpecificationsSystem Specifications• Carriage Width:• Carriage Length:• Carriage Mass:• Coating:• Height Adjustment Options:• Compatible Barriers:53mm245mm2.38kgHot dip galvanised to AS NZS 1214+50mm, +100mm, +150mm, +180mmEzy-Guard Smart, Ezy-Guard 4 and Ezy-Guard HDApproved Variants Approved Variants
| Title | Type | Size | |
| Ingal Ezy-Lift Data Sheet v.0417 | 527 KB | Download |
Got Questions?
Frequently asked questions
- What is the Ezy-Lift carriage designed to do?View
The Ezy-Lift is a height-adjustment carriage that allows existing Ezy-Guard systems to be raised by +50 mm, +100 mm, +150 mm or +180 mm ensuring the barrier remains compliant even after a road surface overlay.
- Does using the Ezy-Lift require replacing all barrier posts and rails?View
No the advantage of the Ezy-Lift carriage is that you don’t need to replace the posts or rails, you simply install the carriage to raise the existing system by the required amount.
- Does using Ezy-Lift affect barrier performance?View
No. When installed according to the product manual, the barrier continues to meet MASH TL-3 performance standards and remains Austroads ASBAP-accepted.
