ArmorZone MASH
ArmorZone MASH

Description Downloads
The ArmorZone MASH Temporary Safety Barrier is a water-filled, modular system designed for quick deployment in temporary work zones. It meets MASH TL1 and TL2 standards, providing reliable vehicle containment at speeds up to 70 km/h. Lightweight and easy to install, it’s ideal for various roadside applications.
Contact Us
Product Information
Product Information

Product Information Product Information

  • Description Description
    Description
    The ArmorZone MASH Temporary Safety Barrier is a modular, water-filled barrier system designed for superior protection in temporary construction zones. It meets both MASH TL1 and TL2 standards, providing robust vehicle containment and redirection at impact speeds up to 70 km/h. The system is lightweight and easy to install, making it ideal for rapid deployment in various roadside and median applications.
    Features Features
    Features
    • Crash tested and approved to MASH TL2 and MASH TL1
    • Accepted by the Austroads Safety Barrier Assessment Panel (ASBAP)
    • Designed in accordance with AS/NZS 3845.1 Road Safety Barrier Systems & Devices
    • Constructed from UV-stabilised, 100% recyclable HDPE for long-term durability
    • Empty units weigh 56kg and can be handled by two operators with no tools required
    • Deployment rate of 120m per hour
    • Container friendly dimensions allow 84 units to fit in a 40ft container
    • Suitable for verge and median applications
    • Can be installed straight or curved down to a minimum 28m radius
    • Smooth surfaces and geometry, more forgiving on vulnerable road users
    • Optional Water-Opening-Screen to prevent rubbish disposal in barriers
  • System Specifications System Specifications
    System Specifications
    • Unit Length:
    • Height:
    • Width:
    • Material:
    • Weight (Empty):
    • Weight (Full):
    • Water Required:
    • MASH TL2 Dynamic Deflection:
    • MASH TL1 Dynamic Deflection:
    2000mm
    860mm
    450mm
    HD Stabilised PE (UV8)
    56kg
    496kg
    440L per unit
    4.10m at 70 km/h
    2.16m at 50 km/h
    • Downloads Downloads
    Downloads
Title Type Size
ArmorZone MASH Data Sheet v.0325 pdf 588 KB Download
ArmorZone MASH Product Manual v.0120 pdf 3946 KB Download
ArmorZone Visual Parts List v.0519 pdf 1250 KB Download
